10W 700mA 0-10V CC Driver PUP10A-1WMC-700

Short Description:

Single channel output, output current level selectable by DIP S.W.

Support 3-in-1 dimming mode:0-10V active signal, adjustable resistance, PWM(A model)

Input voltage of 120VAC ~ 277VAC

Dimming range: 0.1-100%,Dimming effect smooth, no flicker

Protections: Short circuit, Over load,Over voltage

Suitable for indoor LED lighting application


  • :
  • :
  • Product Detail

    Product Tags

    Summary

    PUP10A-1WMC-700 is a constant current output mode LED driver. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the users and luminaire system during installation.

    Technical Paramaters

    Model PUP10A-1WMC-700
    Input Efficiency 78%@120VAC, Full load
    Frequency 50/60Hz
    Voltage 120VAC-277VAC
    PF 0.98@120VAC, Full load
    THD(full load) <10%@120VAC, Full load
    Current 0.13Amax@120VAC
    Inrush Current Cold start,30A@120VAC
    Standby Power <1W
    Output Current/Voltage/Power 350mA/2-21V/7.35W 450mA/2-21V/9.45W 550mA/2-18V/9.9W 650mA/2-15V/9.75W400mA/2-21V/8.4W 500mA/2-20V/10W 600mA/2-16V/9.6W 700mA/2-14V/9.8W
    Channel 1
    No load output voltage 58V Max
    Frequency 1KHz Min PWM
    Current Accuracy ±5%
    LF current ripple(<120Hz) <3%
    Protection Over Voltage Hiccup, recovers after fault condition is removed
    Over load Hiccup, recovers after fault condition is removed
    Short circuit Close output, recovers automatically after fault removed

    Safety & EMC

    Surge L-N:1KV
    Withstand Voltage I/P-O/P: 3000VAC/1min/5mA; I/P-Gnd: 1500VAC/1min/5mA; O/P-Gnd: 500VAC/1min/5m
    Safety standards UL8750/UL1310/CSA25013,CSA class P
    EMI Eission EN55015,EN61000-3-2 Class C,IEC61000-3-3
    EMC Immunity FCC class B(120V)/class A(277V)
    Function Dimming type 0-10V(Type A)
    Dimming range 0.1%-100% Dimming to off




    Others

    Dimension 75*35*26.5mm(L*W*H)(2.95*1.37*1.04Inch)(L*W*H)
    Pack Information N.W: 96g(0.21 lb)±5%/PCS; 100PCS/Carton; 10.1kg(22 lb)±5%/Carton; Carton Size: 398x210x208mm(15.6*8.26*8.18 Inch)(L*W*H)
    IP rating IP20
    Working temp. -20℃~50℃(-4°F~122°F)
    tc 90℃ (194°F)
    Relative humidity 20~90% RH
    Lifetime 50,000h@tc:85℃(185°F)
    Material PC
    Switch cycle >25,000 times

    Applications

    1

    Dimming Curve

    3

    Current Selection Table

    PUP10A-1WMC-700 is a multi-current dimming driver, output current level selectable by DIP S.W., as the following:

    PUP10A-1WMC-700table

    Remark: Function default setting is: 350mA (@switch are all OFF state)

    Type HL Class P Output type-CC Dry and Damp location Class 2 Ground enclosure in installation

    For Connections Use Wire Rated for at Least 90 ℃(194°F) Wired control Circuits lsolated, Use only within an enclosure More than one power supply present

    4

    Cautions

    1.This product should be installed by qualified personnel.

    2.This product is non waterproof, need to avoid sun and rain.In case of outdoor use, please ensure it is mounted in a water proof enclosure.

    3.Good heat dissipation conditions extend product life.Please install the product in a well-ventilated environment.

    4.Please make sure LED power supply output voltage, current is used to meet the product requirements.

    5.Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current. Please also ensure that the cable is secured tightly in the connector.

    6.Due to safety concerns, PVC or rubber cord of 0.75-2.5mm2 is recommended for input and output terminal(s) (excluding signal terminals). Flat power cord is not suitable.Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.

    7.In case of malfunction, do not repair it yourself.
