60W 12VDC Non-dimmable Waterproof CV Driver PEE60-1W12V

Short Description:

·Width voltage input,full power output

·Insolated PC design

·Isolated design,safe and reliable

·Protections:Over load,Short circuit,over voltage

·Comply with UL/FCC CE/SELV

·Protection grades is as high as IP67

·2 years warranty


Product Detail

Product Tags

60W 12VDC Non-dimmable CV Driver PEE60-1W12V

Features

·Width voltage input,full power output
·Insolated PC design
·Isolated design,safe and reliable
·Protections:Over load,Short circuit,over voltage
·Comply with UL/FCC CE/SELV
·Protection grades is as high as IP67
·2 years warranty

Technical Parameters

Model PEE60-1W12V
Input Efficiency 85%@230VAC, Full load
Voltage 120VAC-277VAC
Frequency 50/60Hz
Power Factor ≥0.5@230VAC, full load
Current 1.2Amax@120VAC
Standby Power <0.5W
Inrush Current Cold start 50A@230VAC
Output Current/Voltage/Power 5A/12VDC/60W
Ripple Voltage 90mVp-p
Channel 1
Voltage Tolerance ±2%
Turn On Delay Time <2s, at 230Vac
Protection Short Circuit Auto recovery when failure is removed
Over Voltage <18VDC Shut down the output, After restart recovers automatically.
Over Current <6.5A auto recovery when failure is removed
Safety & EMC Lightning Surge L-N:2kV
Withstand Voltage I/P-O/P:3000VAC/1min/5mA
Safety Standards UL8750(type”HL”),CSA C22.2 No.250.13-12 TUV EN61347-1, EAC TC004,UL60950-1,TUV EN60350-1, EN61347-2-13,J61347-1, J613447-2-13 GB19510.1,GB19510.14
EMC EN55032(CISPR32)ClassB,EN61000-3-2 ClassA EN6100-3-3,EAC TP TC020
EMC Immunity EN61000-4-2,3,4,5,6,8,11 EN55024,EAC TP TC 020
Others Working Temp. -25℃~50℃
Storage Temp.; Humidity -40℃~85℃ 20-90%RH
Tc 90℃
Material PC
IP Rating IP67
Lifetime 17,280h@tc:75℃
Warranty Condition 2 years
Switch Cycle >50,000 times
Packing Size Net weight: 420g±5%/PCS; 30PCS/Carton; 13kg±5%/Carton; Carton Size: 333*218*205mm(L*W*H)
Dimension 165.5*42*34mm(L*W*H)
