40W 12VDC Non-dimmable CV Driver EULP40-1W24V-WS

Short Description:

Product Features

•Supply Voltage: 108-305Vac

•Protection:Short-circuit, Over load, Over Current

•50,000Hour Life @ Tc=80℃

•5 Year Warranty @ Tc<=80℃

•Suitable for indoor LED lighting applications

•UL Class P, Class 2

•Safety according to UL8750 &UL 1310


Product Detail

Product Tags

Summary

EULP40-1W24V-WS is a constant voltage output LED driver.

The compact body is easy to install in small spaces, with stable output and high efficiency.

Product Features

•Supply Voltage: 108-305Vac

•Protection:Short-circuit, Over load, Over Current

•50,000Hour Life @ Tc=80℃

•5 Year Warranty @ Tc<=80℃

•Suitable for indoor LED lighting applications

•UL Class P, Class 2

•Safety according to UL8750 &UL 1310

Technical Parameters

Model EULP40-1W24V-WS




Input

Efficiency >90%@120VAC, full load  >91%@277VAC, full load
Rated Voltage 120-277VAC
Voltage Range 108~305VAC
Frequency Range(Hz) 50/60Hz
Current 0.50Amax@120VAC 0.30Amax@230VAC 0.20Amax@277VAC
Power Factor ≥0.95@120VAC, full load ≥0.9@277VAC, full load
THD(full load) <10%@120VAC <15%@277VAC
Inrush Current(max) Cold start, 15A@120VAC 160us  34A@277VAC 200us




Output

Current Range 1.67A
Voltage Range 24VDC
Output Power 40W Max
Channel 1
Voltage Tolerance ±5%
No load power <1W(Hop)
Power limit ≤140%
Ripple ≤960mV
Turn on delay Time ≤0.75s, @120Vac (When the light begins to shine)
 Protection Short-circuit No output, self recovery after troubleshooting
Over load No output, self recovery after troubleshooting
Over Current No output, self recovery after troubleshooting
  Safety& EMC Surge L-N: 2kV L&N-G: 2kV ring wave
Withstand Voltage I/P-O/PI:2000Vac/1min/<5mA, I/P-G:1500Vac/1min/<5mA,  O/P-G:500Vac/1min/<5mA
Safety Standards UL8750 UL1310 CSA25013.CSA Class P
EMC Eission FCC PART15B
EMC Immunity IEC 61000-4-2-3-4-5-6-8-11
Insulation Resisance 5MΩ






Others

Working Temp. -20~+50°C [-4°F~122°F]
Storage Temp., Humidity -40~+90°C [-40°F~194°F]
tc 80℃ [ 176°F ]
Material Metal
IP Rating IP20
Lifetime 50,000h@tc:80°C [ 176°F ]
Warranty Condition 5years
Switch Cycle >25,000 times
Dimension 144*20.4*20mm (5.67*0.80*0.78 Inch)(L*W*H)
Packing(weight) Net weight: 120g(0.26 lb)±5%/PCS; 50PCS/Carton; 6.5kg(14.3 lb)±5%/Carton; Carton Size:320*225*175mm(L*W*H)
