100W 24VDC Non-dimmable CV Driver PES100-1W48V

Short Description:

·full power output

·Insolated PC design

·Isolated design,safe and reliable

·Protections:Over load,Short circuit,over Current

·Protection grades is as high as IP65

·5 years warranty

·No Flicker


Product Detail

Product Tags

100W 24VDC Non-dimmable CV Driver PES100-1W48V

Product Feature

full power output

·Insolated PC design

·Isolated design,safe and reliable

·Protections:Over load,Short circuit,over Current

·Protection grades is as high as IP65

·5 years warranty

·No Flicker

Technical Parameters

Model

PES100-1W48V






Input

Efficiency >89%@230VAC, Full load
Voltage 120VAC-277VAC
Frequency 50/60Hz
Power Factor ≥0.95@230VAC, Full load
THD <10%@230VAC, Full load
Current 1.2Amax@120VAC
No load power <0.5W
Inrush current Cold start,43A@230VAC 312us
Turn On Delay Time ≤0.5 s, at230Vac (When the light begins to shine)




Output

Current/Voltage/Power 2.08A/48VDC/100W
Output Voitage 45-50V
Ripple Current ≤200mV
Channel 1
Voltage Accuracy ±5%
No load output voltage 50.4V max
Protection Over load Drop the voltage, troubleshoot the fault. The output is normal
Short circuit Hiccup, troubleshoot output normal
Over Current Drop the voltage, troubleshoot the fault. The output is normal


Safety & EMC

Lightning Surge L-N:2kV
Withstand Voltage I/P-O/P:3750Vac/1min/<5mA
Safety Standards EN61347-1 EN61347-2-13 UL1310
EMC Emission EN55015 FCC Part 15 Class B
Insulation Resisance 5MΩ






Others

Working Temp. -20 ~40 (-4°F~104°F)
Storage Temp.; Humidity -40 ~75 (-40°F~167°F) 20-90%RH
Tc 75 (167°F)
Material PC
IP Rating IP65℃
Lifetime 50,000h@tc:75 (167°F)
Warranty Condition 5 years
Switch Cycle >25,000 times
Packing Size Net weight: 573g (1.26 lb) ±5%/PCS; 20PCS/Carton; 11.9kg (26.3 lb) ±5%/Carton; Carton Size: 333*218*205mm (13.2*8.58*8.07 Inch) (L*W*H)
Dimension 190*52*38mm (7.48*2.04*1.49 Inch) (L*W*H)
